Twist Drills HW

Product

Drawing

  • Tungsten Carbide [HW]
  • MAN

Article

Description

Machine / Application

  • portable boring machines
  • automatic boring machines
  • CNC machining centers
  • for chip-free drilling of dowel holes in solid woods and wood-based panels

Design

  • centering point
  • cutting Ø = shank Ø
  • 2 negative spurs
  • spiral with back-guide
  • plastic coated
  • HW-tipped

Advantages

  • safe drilling thanks to centering point
  • protection of the hole edge upon exiting thanks to spiral with back guide
  • optimum chip evacuation thanks to plastic coating
  • chip-free hole edges thanks to negative spurs

Notes

  • clamping element: draw-in collet chuck, drill chuck

Table- and picture caption ...

Ø D
[mm] 		L2
[mm] 		Ø d
[mm] 		L1
[mm] 		Z L/R Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

5 35 5,0 70 2+2 L 173145
|
5 35 5,0 70 2+2 R 167929
|
6 35 6,0 70 2+2 R 167930
|
8 35 8,0 70 2+2 R 167932
|
10 35 10 70 2+2 L 173150
|
10 35 10 70 2+2 R 167934
|
4 55 4,0 80 2+2 R 160503
|
4.5 60 4,5 85 2+2 R 160504
|
5 60 5,0 90 2+2 R 160505
|
5.5 65 5,5 100 2+2 R 164243
|
6 65 6,0 100 2+2 R 160506
|
6.5 70 6,5 110 2+2 R 164244
|
7 70 7,0 110 2+2 R 160507
|
8 75 8,0 120 2+2 R 160508
|
8.5 80 8,5 130 2+2 R 164245
|
9 80 9,0 130 2+2 R 160509
|
10 90 10 140 2+2 R 160510
|
11 95 11 150 2+2 R 160511
|
12 100 12 155 2+2 R 160512
|
