CM080 Roughing cutter DP

Product

Drawing

  • Polycrystalline diamond [DP]
  • MEC

Article

Description

Machine / Application

  • Can be used on CNC and gantry machines or robots

Design

  • Wave profile for roughing with low cutting pressure

Advantages

  • Design with a high number of teeth for highest feed rates

Notes

  • Other dimensions and configurations on request

Table- and picture caption ...

Ø D
[mm] 		L2
[mm] 		Ø d
[mm] 		L1
[mm] 		Z Helical direction Shear∡
[°] 		Type L/R Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

4 8,0 4,0 55 2 positive/negative 3 A R 187295
|
8 8,0 8,0 60 4 negative -5 B R 187296
|
8 17 8,0 65 4 positive 3 A R 80463398
|
10 10 10 80 5 negative -5 A R 187297
|
12.7 22 12,7 76.2 4 positive 3 A R 80470541
|
20 31 20 100 4 negative -3 A R 80463343
|
Show 1 to 6 of 6 entries
